Khoom npe:
Sanguinololu V1.3A
Khoom Nta
· Txhawb ntau yam kev sib txuas lus.
· Txhawb zog ntau lub hwj huam
· Kev tsim cov qauv me me - Lub rooj tsav xwm yog 100mm x 50mm (4 "x 2") - ntau tshaj ib ntiv ntev tshaj li ntawm ib lub lag luam
daim ntawv!
· Sanguino clone, Atmel tus ATmega644P - Muab tso rau hauv ATmega1284!
Cov Lus Qhia Txog
Sanguinololu yog ib qho qis-all-in-ib electronics tov rau Exap thiab lwm yam cuab yeej hauv CNC. Nws nta ib qho ntawm Sanguino clone siv cov ATMEGA644P txawm tias lub ATMEGA1284 tau yooj yim nqis rau hauv. Nws plaub qhov siv tau los ntawm Pololu tus pin nrog cov neeg tsav tsheb.
Lub Rooj Tswjhwm Saib tus tsim tawm tus phooj ywg txhawb qhov chaw nres nkoj uas txhawb I2C, SPI, UART, thiab ntau tus ADC pins. Txhua 14 expansion pins yuav siv tau ua GPIO thiab.
Version 1.3a twb tsis hloov software - tus pin assignments nyob li qub thiab koj 1.2+ tau tshaj firmware yuav tsum ua haujlwm no zoo. Qhov hloov kho vajtse:
- Tshem cov Molex HDD connector hauv kev siv ntawm cov twj tso hluav taws xob - tej lub hwj huam khoom siv lub qias 5V teeb liab thaum tsis muaj niam txiv load, yog li nws zoo dua siv lub hwj huam mov ATX 4 ceg thiab 5V voltage regulator.
- Ntxiv ib jumper los pab / lov tes taw USB pib-pib dua. Qhov no yog tias koj tau luam tawm ntawm SD daim ntawv uas siv SDSL koj tuaj yeem disconnect koj lub iPad thiab nws txuas nws tsis muaj kev cuam tshuam ntawm kev luam.
- R7 thiab R8 yog tam sim no 100k pull-up resistors uas yog nyob rau hauv cov kab stepper-pab. Qhov no ua kom cov stepper motors nyob twj ywm tsis taus thiab tsis tsiv thaum lub sij hawm xa cov tshiab firmware, rebooting, thiab lwm yam. Qhov kev tiv thaiv tam sim no rau FTDI yog ploj mus.
- Muaj Z-tsav header ntxiv rau Prusa Mendel.
Daim Ntawv Teev Npe:
1 x Tswj Lub Rooj Tswjhwm Saib Sanguinololu V1.3a
Kuongshun Electronic, yog ib qho ntawm cov tuam txhab tsim lag luam thoob ntiaj teb thiab cov neeg muag khoom ntawm sanguinololu v1.3a uas yog nyob hauv Suav teb, tam sim no muaj cov khoom zoo rau kev muag khoom. Peb tau nruab nrog ib pawg neeg ua hauj lwm thiab paub txog cov neeg ua haujlwm, nrog rau cov khoom zoo siab. Koj tau so assured yuav luv nqi thiab tsawg nqi sanguinololu v1.3a ua nyob rau hauv Tuam Tshoj los ntawm peb thiab xyuas cov pricelist nrog peb.
