Kuongshun Electronic, yog ib lub tuam txhab tsim lag luam thoob ntiaj teb thiab cov neeg muag khoom ntawm kuongshun 1hz -1mhz xr2206 precision function signal generator kit uas yog nyob rau hauv Suav teb, tam sim no muaj cov khoom zoo rau kev muag khoom. Peb tau nruab nrog ib pab pawg ntawm cov kws tshaj lij thiab cov neeg ua haujlwm paub txog, nrog rau cov khoom siv siab heev. Koj tau so assured mus yuav luv nqi thiab luv nqi kuongshun 1hz -1mhz xr2206 precision function signal generator kit ua nyob rau hauv Tuam Tshoj los ntawm peb thiab xyuas cov pricelist nrog peb.

Voltage qhov chaw: 9-12V DC input
Wave: square, sine thiab daim duab peb sab
Impedance: 600 Ohm + 10%
Zaus: 1Hz - 1MHz
Sine yoj
Amplitude: 0 - 3V 9V DC input
Distortion: tsawg dua 1% (ntawm 1kHz)
Flatness: + 0.05 dB 1Hz - 100kHz
Square nthwv dej
Amplitude: 8V (tsis muaj load) 9V DC input
Lub sijhawm nce: tsawg dua 50ns (ntawm 1kHz)
Lub caij nplooj zeeg: tsawg dua 30ns (ntawm 1kHz)
Symmetry: tsawg dua 5% (ntawm 1kHz)
Daim duab peb sab yoj
Amplitude: 0 - 3V 9V DC input
Linearity: tsawg dua 1% (txog 100kHz) 10mA

3 Lub hauv paus teeb kev txiav txim siab, ua raws cov kauj ruam hauv qab no:

1. Cov ntsiab lus ntawm vuam pem hauv ntej board, qis-siab ntawm cov khoom, uas yog thawj cov khoom siv qis, xws li capacitor, resistor, diode, thiab lwm yam.

2. Qhov chaw IC qhov (socket), lub davhlau ya nyob twg blocks, thaum kawg fais fab qhov (socket), adjustable potentiometer.

3. Pins luv li sai tau los txiav lub nraub qaum nrog cov hlais hlais

4 kauj ruam debugging:

Tom qab ua tiav ntawm welding ntawm 1 IC, XR2206, mloog kev taw qhia IC, ntxig nws tuaj yeem ua rau cov nti!

2. Tshawb xyuas IC seb puas tiv thaiv, xws li tiv thaiv kom raug raws sijhawm.

3. Fais fab mov, 5.5 * 2.1 chaw nres nkoj rau fais fab mov, sab hauv tsis zoo polarity. Voltage rau 9-12v fais fab mov. Lub nthwv dej yuav tsis ruaj khov rau ntau tshaj 12v

5 kauj ruam siv

1. J1 jumper cap plug, SIN / TRI xiav terminals tso zis sine yoj (ceeb toom J1, j2 tsuas yog ntxiv ib qho)

2. J2 jumper cap plug, SIN / TRI xiav terminals tso zis daim duab peb sab yoj (ceeb toom J1, j2 tsuas yog ntxiv ib qho)

3. SQU xiav terminals tso zis mem tes

4. AMP: sine yoj, daim duab peb sab yoj amplitude hloov

5. Fine: zaus fine-tuning

6. Coarse: coarse tuning zaus

6 muaj nuj nqi generator schematic daim duab

NA660 7

NA660 1

Cim npe nrov: kuongshun 1hz -1mhz xr2206 precision function signal generator kit lwm tus neeg Suav teb, manufacturers, luv nqi, yuav luv nqi, pricelist, nqe, ua nyob rau hauv Suav teb
